How Does Commercial Electric Work?

Commercial electrical systems require a much larger capacity than residential ones. This is because the incoming power will need to move through a step-down transformer, and then into switchgear in order to distribute it throughout the entire building.

Are you a business owner looking to shop for a new electricity plan? Commercial rates are based on many factors and variables.

Distribution Panels

A distribution panel is a cabinet that houses all the contact breakers, earth leakage units and doorbells in your building. It’s responsible for managing and distributing electricity throughout all circuits in your commercial property. It’s also a vital component in preventing electrical hazards and fires by keeping track of overcurrent protection and monitoring the system. It’s an important part of your building and requires proper installation, regular maintenance, and adherence to electrical codes to ensure it works safely.

The main electrical network delivers power to the distribution panel through a main cable. It’s then distributed to different electrical outlets in your building. Each outlet or circuit is connected to the distribution panel via branch circuit wiring, and each one has its own circuit breaker or fuse. When an appliance or a device overloads with too much current, the circuit breaker or fuse will shut off power to prevent the device from overheating and causing a fire.

If you want to shut off the entire electricity grid for your home, you’ll turn off the main power switch in the meter box or fuse board. However, if you only want to disable the power for certain devices or rooms in your home, you’ll need to use a different switch, such as the one in the distribution panel.

Each distribution panel has a main service breaker that controls the flow of power to other circuits. The breaker will have a number on it that identifies the panel’s amperage capacity. It also provides an on/off switch for all the branch circuits in your building.

The breaker panel will have a step-down transformer, which reduces the incoming voltage to a safer level. The breaker panel itself may be designated as single phase or three-phase, and it’s common for larger industrial or public buildings to use three-phase panels with twin row breakers.

The panel will also include bonding and grounding conductors that connect to your building’s electrical system. The grounding circuit will dissipate any excess energy or any electrical faults through an appropriate path. The bonded and grounded systems help keep your workers, customers, and equipment safe.

Circuit Breakers

The circuit breaker is one of the key parts of a power distribution panel. It protects lines of electricity from overloading or short-circuiting, and cuts off the flow of current when it detects these problems. When you shut off the main breaker, you turn off all power to your house and everything connected to it.

When the electricity in a home or office reaches unsafe levels, it can cause fires or equipment damage. As soon as this happens, a fuse or circuit breaker will blow or trip to open the circuit and stop the flow of electricity. When this occurs, you need to replace the fuse or reset the breaker to restore the electrical flow to normal.

A circuit breaker has two metal contacts that are positioned in a switch mechanism. When a breaker is flipped to the ON position, the contacts are close together and the circuit is closed. If too much current passes through the circuit, it heats up and creates a strong electric arc between the contact points. This heat quickly dissipates, but the potential for damage is still present.

The internal switch mechanism is activated when the metal contacts touch each other and generate an electrical arc. This dissipates much more rapidly than the heat generated by an overloaded circuit, but it can still result in extensive damage. Once the arc is quenched, the internal switch mechanism returns to the OFF position. The breaker now disconnects the electrical circuit from the panel and renders it dead.

There are several reasons why a breaker may be tripped. The most common is an overload of appliances and light fixtures on a single circuit. As the circuit tries to deliver more power than it can handle, the internal sensing mechanism heats up and trips the breaker to break the connection.

Another common reason for a breaker to trip is a ground fault surge. This can occur when a live wire touches a bare copper ground or bond wire, the case of a metal outlet box, or other conductors in the electrical wiring. Again, the circuit breaker immediately trips to prevent a dangerous situation from developing. In some cases, you might notice a burning smell or witness dark discoloration near the outlet box as a result of this type of problem.


A switch works by opening and closing an electric circuit. It has an actuator that responds to inputs and signals, either manually or automatically, to change the state of the switch. The actuator can be a human element such as a lever or button, or it could be an electronic signal from a computer. Switches can also incorporate fuses for added protection against surges.

Electrical switches are often made with contactors that have low resistance, which allows them to stay cool while operating. This helps to regulate the heat they generate and reduce the likelihood of physical damage or failure. Switches are usually rated for their ability to handle the amount of current they can carry. When the limit is reached, the switch may begin to experience physical damage.

There are several different types of commercial switches. For example, a service entrance rated transfer switch is used to connect your business’s primary power source to a backup generator during power outages. This type of switch is essential for ensuring that your business can continue operating during emergencies.

Commercial electricians also use switches to connect and disconnect equipment in a building. These switches are similar to residential switches, but they have the capability to handle higher voltages. In addition, they are usually rated for multiple poles and are designed to be actuated with a multi-pole actuator.

Most commercial wiring is three-phase, which means it has two smaller wires running at 120 volts each and one wider wire that runs at 208-240 volts. This design system helps spread out the electrical load, which prevents overloading of any single wire. Commercial wiring also tends to run inside conduit, which provides insulation and protects it from the elements.

Whether you’re working on a home or a large business, your electrical contractor will need to install the right switch for each situation. The size and style of the switch will depend on the amount of power that will be supplied to it. In addition, the switches must be able to handle any potential overload. If a switch cannot handle the load, it will start to overheat and fail.


Power runs through wires and outlets channel it throughout the building. It may seem simple, but it’s a crucial aspect of safety and energy efficiency. Understanding how these outlets work and the difference between 2-prong and 3-prong types can help you make more informed choices about your electrical usage and upgrade your system when necessary.

Electricians use receptacles to connect wires to appliances and electronics. Most commercial outlets are GFCI (Ground Fault Circuit Interrupters). These types of outlets have an internal breaker that trips when it detects a fault, such as overheating or overloading, preventing electricity from continuing down the line.

Commercial outlets also are often plugged into a grounding rod or bus that’s part of the circuit’s wiring to protect against surges and lightning strikes. The grounding rod or bus is connected to a panel board, which regulates the high voltage to safe levels for usage.

Many older buildings have ungrounded outlets, which can be hazardous. If you notice your breakers are constantly tripping, it may indicate the wiring in your building needs to be upgraded or there’s an issue with your electrical system itself. If you have a building with ungrounded outlets, they should be replaced as soon as possible to ensure your employees and customers’ safety.

Outlets can be oriented with the grounding slot (the round hole in the middle of the receptacle) either up or down, but most electricians prefer to install them so that the grounding slot is facing up. This configuration prevents the cord plug’s prongs from being tipped and becoming exposed to the hot and neutral screw terminals, which could cause a short circuit.

You should always avoid using extension cords or other devices to replace outlets, as they are not designed to provide adequate current for electrical devices. The long-term use of these devices can lead to overheating and can damage the appliance or device itself. Instead, you should rely on Nashville Electrician to install or replace outlets in your commercial building as needed.

The most common outlet issues occur when the receptacle’s circuit wire connections loosen over time due to contraction and expansion of the wiring in the walls, ceiling or attic. This can result in the wires beginning to melt at their outlets and causing fire hazards. If you notice scorch marks or melted plastic on an outlet, you should contact us to perform an inspection to identify and repair the problem quickly for your safety and peace of mind.
